รายละเอียดสินค้า:
การชำระเงิน:
|
| เต้าเสียบสายไฟ: | ตรง | ลักษณะอีเจ็คเตอร์: | อัตราการดูดสูง |
|---|---|---|---|
| จังหวะ: | 40 มม | เส้นผ่านศูนย์กลางลูกสูบ: | 12 - 63มม |
| ขนาดพอร์ต: | M5, G1/8, G1/4, G3/8, G1/2 | วัสดุ: | อลูมิเนียม |
| การตรวจจับตำแหน่ง: | ผ่านเซ็นเซอร์ฮอลล์ | วัสดุโพรบ: | สแตนเลส |
| ความกว้าง: | 20 มม | ช่วงอุณหภูมิ: | -20 ถึง 80 องศาเซลเซียส |
| เน้น: | Phoenix Contact surge protection base element,industrial surge protection device,VAL-MS2+0-BE/FM surge protector |
||
Description:
Description: Phoenix
Product No. :2805321
https://www.achievers-automation.com More Products
The Phoenix Contact MCR - SL - R - UI is a high - performance potentiometer position transducer belonging to the MINI MCR product series. With an ultra - slim 6.2mm width, it is specialized in converting potentiometer position signals into standardized analog signals. It is applicable to potentiometers with a resistance range of 100Ω - 100kΩ and supports flexible configuration of output signals via DIP switches. Equipped with 3 - way isolation and automatic potentiometer detection functions, this module is widely used in industrial automation, process control, and machinery monitoring systems. It ensures accurate and stable signal transmission while simplifying debugging and installation processes, which is essential for improving the reliability of industrial control systems.
Detail:
|
Specification Category
|
Details
|
|
Manufacturer
|
Phoenix Contact
|
|
Product Model
|
VAL-MS2+0-BE/FM
|
|
Order Number
|
2805321
|
|
Product Type
|
Type 2 Surge Protection Base Element
|
|
Product Family
|
VALVETRAB MS
|
|
IEC Test Classification
|
II (Type T2)
|
|
EN Type
|
T2
|
|
Number of Positions
|
2
|
|
Nominal Frequency
|
50 Hz (60 Hz compatible)
|
|
Surge Protection Fault Message
|
Remote indication contact (changeover contact)
|
|
Max Continuous Voltage (Uc)
|
500 V AC
|
|
Rated Load Current (IL)
|
80 A
|
|
Attribute
|
Specifications
|
|
Mounting Type
|
DIN Rail Mounting
|
|
Dimensions (W x H x D)
|
35.6 mm x 96.8 mm x 51.5 mm (incl. 7.5 mm DIN rail)
|
|
Housing Material
|
PBT (Polybutylene Terephthalate)
|
|
Color
|
Black (RAL 9005)
|
|
Flammability Rating
|
UL 94 V-0
|
|
Connection Type (Main)
|
Screw connection (M5 thread); Fork-type cable lug compatible
|
|
Conductor Cross-Section (Main)
|
Rigid: 1.5-35 mm²; Flexible: 1.5-25 mm² (AWG 15-2)
|
|
Connection Type (Remote Contact)
|
Plug-in/screw via COMBICON (M2 thread)
|
|
Insulation Characteristics
|
Overvoltage Category III; Pollution Degree 2; CTI value 600
|
